Post DIY: BMW 2005 645Ci / E63 / Crank Case Vent Valves CCV

Parts Needed:
BMW part # 11127547058 (if replacing both sides you will need two) $22.28 dealer price not after market
This is a Repair kit, pressure regulating valve

Tools Needed:
Torx (I used a Hex 6/32 since I did not have one)
Flat head screwdriver (thinnest one you have we work best)

Steps:
1. Picture 1 - Remove Engine cover. Unscrew 4 torx (4 red arrows).
2. Picture 2 Pop off side Engine covers. Note, these covers will need to be pulled outward and are held by two plug like screws (refer to picture 3 blue arrows right side and picture 4 left side CCV). Pop bottom first and move your hand to pull off the other. Slide the covers down as getting them out could take some time. Driver side with blue arrow is a little tricky as a hose is in the way.
3. Picture 5 (Picture 3 Ride side CCV & Picture 4 Left side CCV) Release 4 of 6 clips/tabs and slowly pull upwards in a sliding downward motion to free the last two clips/tabs. IMPORTANT, if your CCV kit does not have the vacuum hose attachment be very carful in removing the tabs as you will need to re use the cap. Refer to picture 6.
4. Remove damaged/old rubber and spring. Replace with new spring (picture 7) and rubber.
5. Place Cap back on and firmly press down on each tab making sure they fasten. You should hear 6 clicks one for each tab.
6. Repeat steps 3-5 for other CCV
7. Replace both side engine covers
8. Replace top engine cover and screw back 4 torx screws
9. You successfully changed your CCV

Pic 1


Pic 2


Pic 3


Pic 4


Pic 5


Pic 6


Pic 7


GOOD LUCK!!!
Reply With Quote
Advertisement
  #2
Old 10-02-2011, 05:44 PM
bigtyme562 bigtyme562 is offline
Registered User
Location: CA, 562

Join Date: Jan 2010
Posts: 18
Mein Auto: 2005 BMW 645
Additional information -
I received a check engine light on dash along with "Increased emissions". Fault codes fired: 29E8, 29F0, & 29EF Lean mixture faults, found both side crank case vent valves leaking air.


Reply With Quote
  #3
Old 04-21-2012, 08:19 AM
Kdemers Kdemers is offline
Registered User
Location: San Jose, CA

Join Date: Apr 2012
Posts: 10
Mein Auto: 2005 645 ci
Great Procedure

This DIY is fantastic! I had a very annoying loud whistling sound on my 05 645, and discovered that when I loosened the oil cap, which allowed air to enter the engine, the sound changed. I stumbled on this thread, did the rebuild on the CCV valves, and the noise is GONE! I am still getting the "increased emissions" service message, however, and was wondering about how to clear that. Do I have to have it reset, or will it clear itself with driving? I took it on a 40 mile freeway drive to see if that would help, but I still have the "service engine soon" lit up on the dash. I need to get the car smogged (CA) and it will fail immediately with the light on.
Any advice? Thank you!!
Reply With Quote
  #4
Old 04-21-2012, 12:00 PM
bigtyme562 bigtyme562 is offline
Registered User
Location: CA, 562

Join Date: Jan 2010
Posts: 18
Mein Auto: 2005 BMW 645
Kdemers,
The light will not reset it's self. You will need to reset the warring. Autozoon sells thurs for 29.99 or higher. Once u reset/delete the code go take/do your smog check. You will have about 29 miles before the light goes back on if the repair kit did not fix the original issue. You might also want to note the errors whiched fire in case you need to fix other parts/areas.
Reply With Quote
  #5
Old 05-22-2012, 10:37 AM
amar67 amar67 is offline
Registered User
Location: Woodstock, GA

Join Date: Jan 2012
Posts: 31
Mein Auto: BMW 328IS
Quote:
Originally Posted by Kdemers View Post
This DIY is fantastic! I had a very annoying loud whistling sound on my 05 645, and discovered that when I loosened the oil cap, which allowed air to enter the engine, the sound changed. I stumbled on this thread, did the rebuild on the CCV valves, and the noise is GONE! I am still getting the "increased emissions" service message, however, and was wondering about how to clear that. Do I have to have it reset, or will it clear itself with driving? I took it on a 40 mile freeway drive to see if that would help, but I still have the "service engine soon" lit up on the dash. I need to get the car smogged (CA) and it will fail immediately with the light on.
Any advice? Thank you!!
Were you able to get the code cleared or did it go away by itself? also, did the check engine light come back?

Thanks,

- Amar
__________________
Reply With Quote
  #6
Old 05-22-2012, 04:45 PM
Kdemers Kdemers is offline
Registered User
Location: San Jose, CA

Join Date: Apr 2012
Posts: 10
Mein Auto: 2005 645 ci
the code cleared itself for about 100 Miles, luckily I got it smogged right away. It's back on now, and I am going to have to take it in at this point. Sigh.
Attached Thumbnails
Click image for larger version

Name:	IMG_1089.jpg
Views:	316
Size:	126.8 KB
ID:	326197
__________________
2009 X5 3.0 Silver/blk

2005 645ci silver/blk/sport pkg/L7 sound system/SAT/NAV/Black chrome rims/tinted glass/Akebono ceramic pads
Reply With Quote
  #7
Old 05-27-2012, 06:43 PM
amar67 amar67 is offline
Registered User
Location: Woodstock, GA

Join Date: Jan 2012
Posts: 31
Mein Auto: BMW 328IS
Quote:
Originally Posted by Kdemers View Post
the code cleared itself for about 100 Miles, luckily I got it smogged right away. It's back on now, and I am going to have to take it in at this point. Sigh.
Before you take it in, I would recommend you check the code to be sure it's the same codes (P2187 and P2189). also, check your vacuum lines. I have replaced my both my ccv's (the one in Bank 1 was cut all the way around and the rubber diaphragm was completely severed. I replaced both ccv's and used my cheap $35 code reader to reset the codes. I have driven the car for almost 200 miles and so far all clear. So I'm pretty confident at this point the issue was the damaged diaphragm. Today, we took the engine covers off and give a it good inspection and ensured all the visible vacuum lines are secure. we also took the opportunity to clean as much as we could using WD40 and left a lot of WD40 on the hoses and electrical connectors to help keep them from drying out.
__________________

Last edited by amar67; 05-27-2012 at 06:45 PM.
Reply With Quote
  #8
Old 05-30-2012, 03:17 PM
Kdemers Kdemers is offline
Registered User
Location: San Jose, CA

Join Date: Apr 2012
Posts: 10
Mein Auto: 2005 645 ci
I will check all that out, and thank you very much for the advice. The service engine soon light, and corresponding "increased emissions" warning come and go randomly.
__________________
2009 X5 3.0 Silver/blk

2005 645ci silver/blk/sport pkg/L7 sound system/SAT/NAV/Black chrome rims/tinted glass/Akebono ceramic pads
Reply With Quote
  #9
Old 06-05-2012, 08:16 AM
Robbin545i Robbin545i is offline
Registered User
Location: Worcester, MA

Join Date: Apr 2012
Posts: 8
Mein Auto: 2004 545i
Hello i have a trick that worked for me, i have the 545i so we have the same engine, i had ses light on and increased emisions message so i couldent pass inspection, as soon i was deleting the error i was driving for 5 miles and it comes back on , i delete it again and acidently put the car in sport modus( tilt the shifter to the left for manual shifting) and the error never came out in sport modus becose of the high rpm , i drived like that for 150 miles and passed my inspection , but as soon i drive regular in D the check engine light came right out. So this helped me , a try will not harm , good luck
Reply With Quote
  #10
Old 06-11-2012, 01:53 PM
titopanama10 titopanama10 is offline
Officially Welcomed to the 'Fest
Location: panama

Join Date: Feb 2011
Posts: 115
Mein Auto: 650i
Quote:
Originally Posted by bigtyme562 View Post
Parts Needed:
BMW part # 11127547058 (if replacing both sides you will need two) $22.28 dealer price not after market
This is a Repair kit, pressure regulating valve

Tools Needed:
Torx (I used a Hex 6/32 since I did not have one)
Flat head screwdriver (thinnest one you have we work best)

Steps:
1. Picture 1 - Remove Engine cover. Unscrew 4 torx (4 red arrows).
2. Picture 2 Pop off side Engine covers. Note, these covers will need to be pulled outward and are held by two plug like screws (refer to picture 3 blue arrows right side and picture 4 left side CCV). Pop bottom first and move your hand to pull off the other. Slide the covers down as getting them out could take some time. Driver side with blue arrow is a little tricky as a hose is in the way.
3. Picture 5 (Picture 3 Ride side CCV & Picture 4 Left side CCV) Release 4 of 6 clips/tabs and slowly pull upwards in a sliding downward motion to free the last two clips/tabs. IMPORTANT, if your CCV kit does not have the vacuum hose attachment be very carful in removing the tabs as you will need to re use the cap. Refer to picture 6.
4. Remove damaged/old rubber and spring. Replace with new spring (picture 7) and rubber.
5. Place Cap back on and firmly press down on each tab making sure they fasten. You should hear 6 clicks one for each tab.
6. Repeat steps 3-5 for other CCV
7. Replace both side engine covers
8. Replace top engine cover and screw back 4 torx screws
9. You successfully changed your CCV

Pic 1


Pic 2


Pic 3


Pic 4


Pic 5


Pic 6


Pic 7


GOOD LUCK!!!


hello , nice DIY , i just changed mine, but no vacuum hoses , its that normal?
Reply With Quote
  #11
Old 10-17-2012, 02:19 PM
slemmer slemmer is offline
Officially Welcomed to the 'Fest
Location: mississauga

Join Date: Jul 2003
Posts: 39
Mein Auto: '04 645cic '00 740i Sport
Is this replacement necessary if no codes are shown but the Increased Emissions warning is displayed? Are there any other suggesions for the same light but no codes on the scanner? I'd hate to go through the tear down only to find my CCV are ok. Thanks.. Stephen
Reply With Quote
  #12
Old 10-17-2012, 06:32 PM
Yorgi's Avatar
Yorgi Yorgi is online now
Officially Welcomed to the 'Fest
Location: Toronto

Join Date: Mar 2005
Posts: 3,497
Mein Auto: '04 M3 / '06 650i Cab
Quote:
Originally Posted by slemmer View Post
Is this replacement necessary if no codes are shown but the Increased Emissions warning is displayed? Are there any other suggesions for the same light but no codes on the scanner? I'd hate to go through the tear down only to find my CCV are ok. Thanks.. Stephen
If I had an Increases Emissions message and there were no codes I would change the CCV valves as a first step. They are low cost and very easy to replace. They are also a wear item and will eventually fail so it's not a bad idea to change them even if they don't fix the Increases Emissions message.

Do a search for "increased emissions" , there are many threads with lists of possible causes.
__________________
Straight lines are for fast cars...turns are for fast drivers
'04 M3 - track
'06 650i Cab - daily driver
'02 Highlander - kid hauler
'01 330Ci - winter beater

Reply With Quote
  #13
Old 10-18-2012, 09:26 AM
slemmer slemmer is offline
Officially Welcomed to the 'Fest
Location: mississauga

Join Date: Jul 2003
Posts: 39
Mein Auto: '04 645cic '00 740i Sport
The ses light has mysteriously disappeared after a couple of days of driving. I've picked up two repair kits as per Yorgi's suggestion - plus it's easy to do too. Let's see what happens afterwards.
Reply With Quote
  #14
Old 10-18-2012, 05:55 PM
slemmer slemmer is offline
Officially Welcomed to the 'Fest
Location: mississauga

Join Date: Jul 2003
Posts: 39
Mein Auto: '04 645cic '00 740i Sport
Ok, I did the repair. Weird that the replacement cap didn't have a vacuum hose nib attached to it but the older one has the nib molded to the cap. Does anyone know the part number of the add on vacuum hose nib? Thanks. Stephen.
Reply With Quote
  #15
Old 10-19-2012, 12:12 AM
Yorgi's Avatar
Yorgi Yorgi is online now
Officially Welcomed to the 'Fest
Location: Toronto

Join Date: Mar 2005
Posts: 3,497
Mein Auto: '04 M3 / '06 650i Cab
Quote:
Originally Posted by slemmer View Post
Ok, I did the repair. Weird that the replacement cap didn't have a vacuum hose nib attached to it but the older one has the nib molded to the cap. Does anyone know the part number of the add on vacuum hose nib? Thanks. Stephen.
From the DIY above:
>> IMPORTANT, if your CCV kit does not have the vacuum hose attachment be very carful in removing the tabs as you will need to re use the cap. Refer to picture 6.

I believe that extra vacuum line goes to the fuel pressure regulator. On newer cars this line has been eliminated but you need to attach it to the CCV if your car has that extra line.
__________________
Straight lines are for fast cars...turns are for fast drivers
'04 M3 - track
'06 650i Cab - daily driver
'02 Highlander - kid hauler
'01 330Ci - winter beater

Reply With Quote
  #16
Old 10-19-2012, 03:22 PM
sam573 sam573 is offline
Registered User
Location: Canada

Join Date: Oct 2012
Posts: 2
Mein Auto: 2005 545i
One of my caps broke on the replacement, i called BMW because the diagram with the part showed the vent connection. They said it was no longer needed and you can plug the hose to the MAF. I'm not sure if i can do that and am looking for a second opinion
Reply With Quote
  #17
Old 11-22-2012, 04:18 PM
HP04PEA HP04PEA is offline
Registered User
Location: West Yorkshire

Join Date: Aug 2012
Posts: 10
Mein Auto: 645Ci
New to this site and only posting my 2nd thread, can I ask what was it that drove you to changing your CCV valves? I cannot find in this thread why yours needed replacing.

I have a 645 that blows blue smoke after standing idle for any length of time and have read it could be CCV Valves. I'm praying this is the solution as the alternative fault (valve stem oil seals) is highly expensive.

Kind regards

Harry
Reply With Quote
  #18
Old 12-07-2012, 12:22 PM
HULKED HULKED is offline
Registered User
Location: South Africa

Join Date: Sep 2012
Posts: 15
Send a message via Skype™ to HULKED
Mein Auto: BMW 650i Cab
I had same problem & i changed the 2 ccv valves no more smoking at idle.
__________________
Reply With Quote
  #19
Old 12-07-2012, 12:37 PM
HP04PEA HP04PEA is offline
Registered User
Location: West Yorkshire

Join Date: Aug 2012
Posts: 10
Mein Auto: 645Ci
Exclamation 645 ccv valves

Hulked,

Thank you for getting back to me. I decided to trade the old girl in for a newer 320d. I miss her but I can't help smiling each time I look at the trip computer on the new one and it shows 675 miles to your next visit to the filling station!

I really appreciate you tok the time to reply and hope you enjoy your 6 as much as I enjoyed mine.

Ps. I only decided to get the 320d after reading so many rave reviews on here about them. I almost went for the 330d but traffic in the UK and speed cameras around every corner have taken all the fun out of going anywhere in your car so took the sensible option.

Regards

Harry
Reply With Quote
  #20
Old 02-26-2013, 06:39 PM
Dass Dass is offline
Registered User
Location: Mississauga

Join Date: Sep 2012
Posts: 11
Mein Auto: 2005 BMW 645ci
Thank you!!!!!!!

I have had this engine light/"increased emission" for the last 7 months. The shop I work with has changed valves, seals and valve covers all over the friggin place totalling about 6g's. Because I have an after market warranty I didn't pay too much attention.

But then the car started stalling and shaking. This time they told me it was the vaccum lines. I let them go at it and again...stalling and emission light.

Then I decided enough was enough.... After reading through this forum I came to understand there was a diagnostic wire specifically targeted or geared towards BMW vehicles. I purchased the Bavarian Technic diagnostics wire and downloaded the software. I found the error messages as listed above which lead me to this thread. I have purchased the ccv pressure valve kit x2 I figure I'll do both sides while I'm at it. There was a slice or hole in the diaphragm. Let's hope this is it, but I'm confident this is or was the issue. Thanks again.

Symptoms again:
Shake at stop.
Stall after warmed up and idling or reverse (low rpms)
Increased emissions light
Engine light
Large cloud of blue smoke on long idle 3-5 min
Spontaneous bouncing rpms at low idle

If at any time I reset/clear the fault all problems were resolved for about 100km

Cheers.

Last edited by Dass; 02-26-2013 at 06:41 PM.
Reply With Quote
  #21
Old 03-21-2013, 07:15 PM
petros2r's Avatar
petros2r petros2r is offline
Ducati fills my BMW's gap
Location: Dallas, TX

Join Date: Jan 2010
Posts: 413
Mein Auto: '05 645ci
Thanks for the write up bigtyme562. I've changed mine today and tomorrow I'll see if the rough idling disappears. Strangely, the driver side orange rubber was new-looking and the passenger side all old and stiff. I went ahead and replaced them both, since I bought 2. So now I have one almost brand-new to give away..
__________________
2005 Ducati Monster S2R 800
2005 BMW 645ci Cabriolet - SOLD
2013 Lexus RX 350 F Sport
Reply With Quote
  #22
Old 05-28-2013, 10:17 AM
hugo_za hugo_za is offline
Officially Welcomed to the 'Fest
Location: Johannesburg, South Africa

Join Date: Mar 2013
Posts: 100
Mein Auto: e39 BMW 540i
Super simple task. Thanks for the DIY. Only had the rough idle but that is gone now. Interesting though is that i have an 12/04 production 645ci convertible and neither of the valves have pipes connected to them.
Reply With Quote
  #23
Old 06-26-2013, 04:21 PM
jeremyp jeremyp is offline
Registered User
Location: NH

Join Date: Oct 2012
Posts: 49
Mein Auto: 2005 545i Sport
bigtyme562, This was a great DIY and very helpful on my 545i. I actually found this thread from a google search on this issue and just followed your lead. This made it super easy to do.

I added a thread in the E60 section and actually put in a link to your DIY so the 5 series guys can get some love too.

JP
Reply With Quote
  #24
Old 07-20-2013, 06:21 AM
nyoung nyoung is offline
Registered User
Location: Atlanta

Join Date: Feb 2013
Posts: 17
Mein Auto: 2005 545i
Crankcase vent hoses

Hello,

Another common problem is the CCV hoses which I was told cause engine leaks. There is a video on youtube about this. If your engine is leaking like mine, now we know why.





Last edited by nyoung; 07-20-2013 at 06:23 AM.
Reply With Quote
  #25
Old 07-25-2013, 08:34 PM
feszty feszty is offline
Registered User
Location: Houston, Texas

Join Date: Jul 2013
Posts: 5
Mein Auto: 2006 BMW 650i E63
I changed my CCVs in my '06 E63 650, hoping that the smoking after idle will go away. It did not fix the smoke issue, but it did improve the idling and the car seems to run better. Thanks for the DIY write-up. If y'all have any other suggestion for the smoke issue? I am afraid that the valve seals are the culprit, as BMW suggested.
Reply With Quote
Reply

Bookmarks


Forum Navigation
Go Back   Bimmerfest - BMW Forums > BMW Model Discussions > 6 Series > 6 Series DIY
Today's Posts Search
Thread Tools
Display Modes

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is On



Forum Jump


All times are GMT -7. The time now is 02:03 PM.


Powered by vBulletin® Version 3.8.7
Copyright ©2000 - 2014, vBulletin Solutions, Inc.
© 2001-2011 performanceIX, Inc. All Rights Reserved .: guidelines .:. privacy .:. terms
